FEL Upper Level Building Zones

ZONE Description 1 Injector Control Racks 2 Secondary Injector Control Racks 3 Beam Instrumentation Control Racks 4 Cryogenics Control Racks 5 D.C. Power (Magnets) & Vacuum System Control Racks 6 Drive Laser Clean Room 7 Laser Control Room 8 High Power Optics Chamber 9 1st User Lab 10 2nd User Lab 11 3rd User Lab 12 4th User Lab 13 5th User Lab 14 6th User Lab 15 P.S.S. Racks and Network & Telecommunications Racks
